VSRF60GE (Gas & Electric) Vaccine Storage Refrigerator and Ice Pack Freezer
The Vaccine Storage Refrigerator is designed to ensure safe and efficient transport of vaccines. With a robust construction and advanced insulation technology, this refrigerator provides optimal temperature control, making it ideal for medical professionals on the go. Its compact size and impressive storage capacity cater to the needs of healthcare facilities, ensuring that vaccines remain protected during transit. Below are the detailed specifications for the Vaccine Storage Refrigerator:
| Specifications |
Details |
| Vaccine Storage Capacity (L) |
Refrigerator: 24L |
| Frozen Ice Pack Storage Capacity (L) |
Freezer: 4 x 0.6L |
| Manufacturers Gross Volume (L) |
Refrigerator: 85L, Freezer: 5.27L |
| Hot Zone Appliance (+43°C) |
YES |
| Refrigerant |
NH3 |
| Min Rated Ambient Temp |
+15ºC |
| Energy Source |
Electric Mains 220-240V or LPG (Gas) |
| Fuel and Cycle Type |
Absorption Cycle |
| Body Material |
Polyethylene |
| Fitted With ASP (AVR) |
YES |
| Power Consumption – Stable Running |
|
| Energy Consumption, Stable |
494 grams/2.95 kWh/24 |
| Running (LPG Gas/Electricity) |
|
| Energy Consumption, Cool |
544 grams/3.03 kWh/24 |
| Down Test (LPG Gas/Electricity) |
|
| Performance Information |
|
| Hold Over Time During Power Cut |
|
| At +43ºC |
3 Hours 4 Minutes |
| At +32ºC |
6 Hours 45 Minutes |
| Ice Pack Freezing (kg/24Hrs) |
2.4 at +32ºC / 1.2 at +43ºC |
| Ice Pack Freezing Day/Night Cycle |
2.4 at +32ºC / 2.4 at +43ºC |
| Dimensions |
|
| Boxed Dimensions (mm) |
(H) 895mm x (W) 1030mm x (D) 775mm |
| Unboxed Dimensions (mm) |
(H) 840mm x (W) 970mm x (D) 700mm |
| Weight (Kg's) - unboxed |
56kg |
| Shipping Volume (Crated) |
0.717 m³ |
| Weight Crated |
70kg |
| Container Quantities |
|
| 20' |
34 |
| 40' |
70 |
| 40' HC |
103 |
