Soil Moisture, Temperature, And Salinity Recorder
Feature:
Ø Small and exquisite, easy to carry and LCD display;
Ø Collect settings: working unattended can be set to timing or manual collect data, recording and save data automatically;
Ø Both AC and DC available, internal lithium battery: 8.4v 1500mAh, with function: charging protection, low voltage prompt. Also can be placed for a long time to record location;
Ø Storage capacity: up to 30,000 groups in handset, and standard equipped with 4G Micro SD.
Ø Data can be read on handset and also import to PC.
Ø Power-off memory function: data already saved in SD card won’t lose when lose power.
Ø Probe to probe Consistency, handset can connect different kinds sensor by concentrator without influence on accuracy.
Ø Auto detection: when sensor connects to handset, you can search different sensor.
Ø Synchronous detection: 32 channels to detect same time as you combine.
Ø RS485 wire communication, sensor communication cables could reach about 100 meters.
Ø Low-power design, equipped with system monitor and protection function to avoid short circuit or interference from external.
Software：
Ø Showing the curve trends of each parameter, Max, Min, and Avg. Zoom in and out function.
Ø Coloring the overrun area function which is visual display.
Ø Save the data in EXCEL format as a copy.
Ø Be able to view period of parameter or graph, and can be printed.
Ø All curvilinear coordinates can be set and move, which make analysis easier.
Technical Parameters:
| Model |
SMTS-3P |
| Function |
Detect soil moisture, content temperature, and salinity same time |
| Soil Temperature |
Unit: °C
Range: -40°C~100°C
Accuracy: ±0.5°C
Resolution: 0.1°C
|
| Soil Moisture Content |
Unit: %(m³ )
Range: 0~100%
Response time: ≤ 2s
Relative error: ≤3%
|
| Soil Salinity |
Range: 0~19.99ms/cm
Sensors can be buried into soil.
|
| Storage Capacity |
Almost up to 30,000 groups in handset, and equipped with 4G Micro SD. |
| Data-Collection Interval |
5min~99hour |
| Working Power Supply |
Battery: 8.4V lithium battery;
Power Adapter:100~240V 50/60Hz
|
| Working Current |
Stand-by power consumption 10mA, working power consumption according to the configuration. |
| Package Size(L*W*H) mm |
450*420*140 |
| Gross weight (kg) |
4 |
