MERIL MOZEC SEB NANOTECH NOVEL DRUG DELIVERY CATHETER

MOZEC^TM SEB offers controlled and targeted sirolimus drug release. Nanotech Novel Drug Delivery System features a unique formulation of Solid lipid nano spheres (SLN) consisting of sirolimus and lipid spheres. Deliverability enhanced with Mozec PTCA catheter:

• PTFE coated proximal shaft for enhanced navigability and cross challenging lesions.
• Low tip profile and semi-compliant balloon material allowing flat compliance.
• Transparent ergonomic hub displaying balloon dimensions with flexible distal segment and pushable proximal segment.

Catheter Design	Rapid Exchange
Tip Entry Profile	0.016”
Crossing Profile	0.024”
Balloon material composition	NovalonTM
Balloon Compliance	Semi-Compliant
Hydrophilic Coating	MeriGlideTM – from base of distal tip to Rx-port
Nominal	7atm
RBP	16atm for 2 to 4mm diameters; 14atm for 4.5mm diameter



DIAMETER / LENGTH	9 MM	12 MM	14 MM	15 MM
2.00 mm	MOZS20009	MOZS20012	MOZS20014	MOZS20015
2.25 mm	MOZS22509		MOZS22514
2.50 mm	MOZS25009		MOZS25014
2.75 mm	MOZS27509		MOZS27514
3.00 mm	MOZS30009		MOZS30014
3.50 mm	MOZS35009		MOZS35014
4.00 mm	MOZS40009		MOZS40014
4.50 mm	MOZS45009		MOZS45014



DIAMETER / LENGTH	17 MM	20 MM	25 MM	30 MM
2.00 mm	MOZS20017	MOZS20020	MOZS20025	MOZS20030
2.25 mm	MOZS22517	MOZS22520	MOZS22525	MOZS22530
2.50 mm	MOZS25017	MOZS25020	MOZS25025	MOZS25030
2.75 mm	MOZS27517	MOZS27520	MOZS27525	MOZS27530
3.00 mm	MOZS30017	MOZS30020	MOZS30025	MOZS30030
3.50 mm	MOZS35017	MOZS35020	MOZS35025	MOZS35030
4.00 mm	MOZS40017	MOZS40020	MOZS40025	MOZS40030
4.50 mm	MOZS45017	MOZS45020	MOZS45025	MOZS45030
