High Performance Material
The leaflets and hinge ring are made of pyrolytic carbon, which guarantees the excellent biocompatibility and superior safety.
Open Pivot Design
Open pivot design ensures the sufficient blood washing to reduce the risk of thrombosis.
This design reduces the shear stress that acts on the blood cells to minimize the damage.
85° Leaflet Opening
The 85° leaflet opening provides improved laminar flow, reduces the turbulence, and optimizes the transvalvular gradients.
Suspending Leaflets
Suspending leaflet design enables the fast opening and closing to guarantee the physiological needs.
Lower Noise
Smooth buffering reduces the noise when the leaflets open and close, providing quieter impact for better life.
| SIZES |
TAD(MM) |
OUTER DIAMETER(MM) |
INNER DIAMETER(MM) |
| 19A |
16.2 |
19.8 |
14.8 |
| 21A |
18.2 |
21.8 |
16.8 |
| 23A |
20.2 |
23.8 |
18.8 |
| 25A |
22.2 |
25.8 |
20.8 |
| 27A |
24.2 |
27.8 |
22.8 |
| 16AP |
16.2 |
16.2 |
14.8 |
| 18AP |
18.2 |
18.2 |
16.8 |
| 20AP |
20.2 |
20.2 |
18.8 |
| 23M |
20.2 |
23.8 |
18.8 |
| 25M |
22.2 |
25.8 |
20.8 |
| 27M |
24.2 |
27.8 |
22.8 |
| 29M |
26.2 |
29.8 |
24.8 |
| 31M |
28.2 |
31.8 |
26.8 |
| 33M |
28.2 |
33.8 |
26.8 |
| AORTIC: |
Available in Size 19,21,23,25,27 |
|
| AORTIC HP (High Performance) |
Available in Size 16,18,&20 |
|
| MITRAL |
Available in Sizes 23,25,27,29,31 & 33 |
