Aspiron is specifically designed to aspirate thrombus rapidly to restore reflow.
Distal hydrophilic coating ensures smooth passage through guide catheter to the vessel with optimal trackability.
Deliverability enhanced by innovative tip design & short and easy to use rapid exchange lumen port.
Short and soft tip design facilitates increased safety during aspiration procedure.
Distal radiopaque marker enables precise positioning.
Proximal transparent hub – Ergonomic handling with kink resistance support.
Short rapid exchange guide wire lumen allows rapid catheter exchange,
clot engagement and aspiration of thrombus.
Rapid Thrombus Management
Aspiration Volume
Large aspiration port facilitates optimal aspiration rate and increased
aspiration volume.
1-Aspiration catheter 1-Stopcock attachment
2-30 ml syringe 2-Thrombus collection basket
1-Extension tube 1-Flushing needle.
ASPIRON TECHNICAL SPECIFICATIONS
Distal Tip Profile : 1.7 F / 0.022”
Surface Aspiration Volume (aspiration area) : 0.8 mm²
Rapid Exchange Port Length : 10 mm
Outer Shaft Diameter – Distal & Proximal : 3.9 F / 1.30 mm
Usable Catheter Length : 140 cm
Guide Catheter Minimum ID Compatibility : 6 F (Min. I.D. 0.070”/ 1.78 mm)
Guidewire Compatibility : 0.014” (0.36 mm)
Maximum Outer Diameter : 5.1F / 1.70 mm
