Horizontal Laminar Flow Cabinet BBS-H1300 BBS-H1800
Laminar Flow Cabinet – is used only for sample protection.
Laminar Flow Cabinet is a work bench or similar enclosure, which creates a particle-free working environment by taking air through a filtration system and exhausting it across a work surface in a laminar or unidirectional air stream.
Models:
| Model |
BBS-H1300 |
BBS-H1800 |
| External Size（W*D*H） |
1300*820*2040mm |
1800*820*2070mm |
| Internal Size（W*D*H） |
1200*500*570mm |
1700*500*570mm |
| Work Surface Height |
750mm |
| Display |
LCD Display |
| Airflow Velocity |
Average of 0.3~0.5m/s |
| Material |
Main Body: Cold-rolled steel with anti-bacteria powder coating |
| Work Table: 304 stainless steel |
| Side and Front Window: 5mm toughened glass, anti-UV |
| Pre-filter |
Polyester fiber, washable |
| HEPA Filter |
99.995% efficiency at 0.3μm |
| Noise |
<65dB |
| Front Window |
Motorized |
| Max Opening |
430mm |
| LED Lamp |
12W*1 |
16W*2 |
| UV Lamp |
30W*1 |
30W*1 |
| Emission of 253.7 nanometers |
| Consumption |
400W |
500W |
| Waterproof Socket |
Two, total load≤500W |
| Caster |
Universal caster with leveling feet |
| Power Supply |
AC220V±10%, 50/60Hz; 110V±10%, 60Hz |
| Standard Accessory |
LED lamp;
UV lamp*2;
Base stand;
Gas Tap;
Waterproof socket*2;
Water Tap (only for BBS-H1800).
|
| Optional Accessory |
Electric height adjustable base stand |
| Gross Weight |
254kg |
328kg |
| Package Size（W*D*H） |
1450*1060*1650mm |
1950*1060*1600mm |
Laminar Flow Cabinet – is used only for sample protection. Laminar Flow Cabinet is a work bench or similar enclosure, which creates a particle-free working environment by taking air through a filtration system and exhausting it across a work surface in a laminar or unidirectional air stream.
