Description for BTL 08 MT Plus 12-channel ECG Machine with accessories
The professional MMT table for X-Ray Machine is Cutting-edge medical imaging accessory designed to optimize patient positioning and enhance diagnostic precision. With its durable construction and adjustable features, this table provides a stable platform for various X-ray procedures. The MMT table ensures seamless integration with X-Ray equipment, prioritizing both patient comfort and imaging accuracy in medical settings.
Key Features:
- 12-channel ECG with 112 mm printouts
- optimized workflow
- Hight Quality A5 printouts
- Spirometry Upgrade
- Diagnostic software
- BTL Cardio point
- Unlimited number of profiles for automatic and manual mode
- Unlimited number of profiles for long ECG recordings
- Optional Diagnostic ( includes: averaging, analysis, text interpretation)
- Optional PC connection with software BTL Cardio point ECG
- Optional ergometry with software BTL cardio point Ergo
- Optional WiFi & LAN communication with PC
Specifications of BTL 08 MT Plus 12-channel ECG Machine with accessories:
Product Name BTL 08 MT Plus 12-channel ECG Machine with accessories
Brand BTL
Modal Name/ Number 08 MT Plus
Input Impedance Greater than 20 M Ohm
Common Mode Rejection Greater than 100 dB
Accumulator Capacity Automate upto 30 prints
Maximum Consistent Voltage +-5V
Screen Resolution 640 × 480 px
Sampling Frequency ECG 2000 Hz
Dynamic Range 15.9 mV Polarization Voltage
Paper Width 112 mm
Interface RS 232, USB, LAN (optional), WiFi (optional)
Charging TIme 4-6 hours
Polarisation voltage ± 400 mV
A and D conversions 13 bits
Frequency response 0.05–170 Hz
Displayed leads 3, 6, 12
Number of Leads 12
Paper Speed 5, 10, 25, 50 mm/s
Display 5.7 inches color touch screen
Paper Type Roll/A4-office paper
Automatic Auto adaptive
Digital resolution 3.9 microvolt
Power supply 115 / 230 V, 50-60 Hz
Dimensions 330 x 270 x 74 mm
Weight Approximate 3.2 kg
