Biological Microscope BM-2CBA
Technical Parameters:
| Model |
BM-2CBA |
| View Head |
Compensation free binocular head, Inclined at 30°, 360° rotatable, Interpupillary 55~75mm |
| Eyepiece |
P10X/18mm, P16X/11mm |
| Achromatic Objective |
4X N.A=0.10 WD=37.50mm |
| 10X N.A=0.25 WD=7.31mm |
| 40X N.A=0.65 WD=0.63mm |
| 100X(Oil) N.A=1.25 WD=0.18mm |
| Focusing |
Coaxial Coarse ＆ Fine Adjustable System, Range 15mm, Fine Division 0.002mm |
| Stage |
Mechanical Stage 130*125mm, Moving Range 70*30mm, Vernier 0.1mm |
| Condenser |
Abbe NA1.25 centerable condenser with Iris Diaphragm ＆ Filter |
| Illumination |
LED lamp, brightness adjustable |
| Filter |
Blue, yellow, green |
| Power Supply |
AC85~265V， 50/60Hz |
| Package Size |
335*215*470mm |
| Gross Weight |
5.5kg |
Explore the intricacies of life at the cellular level, conduct live specimen observations, and facilitate interactive learning experiences. The Biological Microscope brings the wonders of the microscopic world into focus with clarity and precision.
