BIOBASE BMM-1000 BMM-2000 Multi-function Digital Biological Microscope
Technical Parameters:
| Model |
BMM-1000 |
BMM-2000 |
| Optical System |
Infinite optical system |
/ |
√ |
| Viewing Head |
Siedentopf binocular viewing head, inclined at 30°, 360° rotatable, Interpupillary 48~75mm |
√ |
√ |
| Siedentopf trinocular viewing head, inclined at 30°, 360° rotatable, Interpupillary 48~75mm |
● |
● |
| Eyepiece |
WF10x/18 |
|
|
| P16x/11 |
● |
|
| WF10x/20 |
|
√ |
| WF15x/16 |
|
● |
| Objective |
Achromatic objective 4x, 10x, 40x,100x |
√ |
|
| Plan achromatic objective 4x, 10x, 40x,100x |
● |
|
| Infinite plan achromatic objective 20X，60X |
|
● |
| Infinite plan achromatic objective 4X，10X, 40X, 100X |
● |
√ |
| Nosepiece |
Quadruple nosepiece |
√ |
|
| Backward quadruple nosepiece |
|
√ |
| Backward quintuple nosepiece |
|
● |
| Focusing |
Coaxial coarse & fine adjustment,fine division 0.002mm,coarse stroke 37.7mm per rotation,fine stroke 0.2mm per rotation .moving range 20mm |
√ |
|
| Stage |
Double layers mechanical stage:132*142mm, moving range:75*40mm |
√ |
|
| Rectangular 230*150mm stage, moving range:78*54mm, using low-positioned X/Y coaxial control knob |
|
√ |
| Condenser |
Abbe condenser NA1.25 with aperture diaphragm |
√ |
√ |
| Illumination |
S-LED Illumination, brightness adjustable |
√ |
√ |
| 12V/20W Halogen lamp, brightness adjustable |
● |
● |
| Kohler illumination |
● |
● |
| Power Supply |
110-220V, 50/60HZ |
√ |
√ |
| Accessories |
Photo attachment, video attachment |
● |
● |
| Dark field condensor |
● |
|
| Polarization set, phase contrast kit |
|
● |
| Package Size |
323*264*440mm(BMM-1000), 380*260*510mm(BMM-2000) |
√ |
√ |
| Gross Weight |
6.5kg(BMM-1000), 10kg(BMM-2000) |
√ |
√ |
Note: √ Standard Outfit, Optional Without this feature
LCD digital biological microscope is a research level microscope which has been specially designed for college education, medical and laboratory research. The microscope has a 6.0MP high sensitive camera and 11.6″ 1080P full HD retina LCD screen. Both traditional eyepieces and an LCD screen can be used for convenient and comfortable viewing. The modular design allows for various viewing modes such as brightfield, darkfield, phase contrast, fluorescence and simple polarizing.
